Waves

Waves are the fundamental driver of vessel motion and, consequently, the reason heave compensation exists. Understanding wave characteristics (height, period, and spectral distribution) is essential for specifying compensators, planning marine operations, and determining operational weather windows.

Key Wave Parameters

Ocean waves are irregular and random, but they can be described statistically using a few key parameters:

  • Significant wave height (Hs) — Classically the mean height of the highest one-third of waves; in spectral work it is computed from the wave spectrum (Hm0), which closely approximates it. This is the standard measure of sea severity used in offshore engineering and corresponds roughly to what an experienced observer would estimate as the wave height.
  • Peak spectral period (Tp) — The wave period at which the wave energy spectrum has its maximum. The governing values are site- and season-specific — wind sea and swell carry different periods, and the project metocean basis states both.
  • Zero-crossing period (Tz) — The average period between successive upward zero crossings of the sea surface elevation. Related to Tp by factors that depend on the spectral shape.

Both Hs and Tp are critical inputs for heave compensator design — but neither sets the specification alone. Stroke and velocity come from the modelled relative motion of the actual vessel, crane and payload in that sea state, and Tp drives where the dynamic-response and resonance checks land.

Key wave parameters — significant wave height, peak period and zero-crossing period defined, and what each one drives.
ParameterDefinitionWhat it drives
HsAverage of the highest third of wavesSea severity — and the required compensator stroke
TpPeriod at the spectrum’s energy peak (5 – 15+ s)Dynamic response and the resonance-avoidance strategy
TzMean zero-crossing periodRelated to Tp by the spectral shape

Wave Spectra

Because ocean waves are irregular, engineers describe them using a wave energy spectrum — a function showing how wave energy is distributed across frequencies. Two standard spectral models are widely used in offshore engineering:

  • Pierson-Moskowitz (PM) — Describes a fully developed sea in deep water, defined by Hs alone. Suitable for open ocean conditions where wind has blown over a long fetch for an extended period.
  • JONSWAP — A modification of the PM spectrum with an additional peak enhancement factor (γ, typically 1.0–7.0). Represents a developing sea with a sharper spectral peak. The default γ = 3.3 is commonly used for North Sea conditions.

The choice of spectrum affects the predicted vessel motions and, consequently, the crane tip heave that the compensator must absorb. JONSWAP spectra with high γ values concentrate energy near the peak period — whether that raises or lowers the response depends on where the peak sits relative to the system’s transfer functions.

PIERSON-MOSKOWITZFully developed deep-water sea, defined by Hs alone — long-fetch open ocean.
vs
JONSWAPDeveloping sea with peak enhancement γ (1.0–7.0, default 3.3 for the North Sea) — a sharper, narrower energy band that is harder on resonance avoidance.

The wave spectrum — same Hs, two shapes

Plotting wave energy against period turns the two model names into shapes. Same sea severity (same Hs) but the energy sits differently:

WAVE ENERGY SPECTRUM · SAME Hs, TWO SHAPES ILLUSTRATIVE 5 10 15 20 WAVE PERIOD T (s) WAVE ENERGY DENSITY Tp — spectral peak JONSWAP γ = 3.3 the North Sea default PIERSON–MOSKOWITZ fully developed · broad band narrow band AREA = TOTAL ENERGY → sets Hs Both curves hold the same total energy — the same Hs — distributed differently across period. JONSWAP’s narrow band concentrates it near Tp — more challenging for resonance avoidance.

Tp marks the spectral peak; the shaded areas (the total energy, which sets Hs) are equal. The JONSWAP form (γ = 3.3, the North Sea default) concentrates that energy into a narrower band around Tp, which is what makes a developing sea harder on resonance avoidance than the broad, fully developed Pierson–Moskowitz shape.

Sea States and Operational Limits

Offshore operations are planned around sea state forecasts that specify Hs and Tp (and sometimes directional spreading and swell components). Each marine operation has defined limiting criteria — usually an Hs–Tp envelope, qualified by direction, wind and forecast uncertainty rather than a single Hs number.

The operational limit is typically governed by the most sensitive phase of the operation — often the splash zone crossing. Heave compensation directly increases this limit by reducing dynamic loads, extending the operational weather window and reducing costly waiting-on-weather time.

Where the suspended-load dynamics govern, compensation moves that envelope — the uncompensated and compensated limits are compared case by case in the lift analysis. This can make the difference between a feasible operation and one that requires an impractically calm weather window.

Waves and Compensator Specification

When specifying a heave compensator, the wave environment determines several key requirements:

  • Compensator stroke — Sized to accommodate the maximum crane tip heave amplitude, derived from Hs and the vessel’s heave RAO.
  • Piston velocity — Driven by the combination of heave amplitude and wave period; shorter periods require faster compensator response.
  • Natural period — Establish the system’s natural modes first, compare them with the excitation band, then verify the selected compensator’s stiffness and damping across the modelled cases.
  • Damping — Sized to control response near resonance whilst maintaining efficiency at typical operating periods.

Norwegian Dynamics provides engineering support to match compensator specifications to site-specific wave data. Whether using the RIGEL for cost-effective operations or the ANTARES for demanding variable conditions, correct wave characterisation is the foundation of effective heave compensation design.

Waves — frequently asked

What is significant wave height (Hs)?
The average of the highest one-third of waves — the standard sea-severity measure, close to what an experienced observer would estimate by eye.
What is the difference between Tp and Tz?
Tp marks the energy peak of the spectrum (5 s sheltered to 15+ s in swell); Tz is the mean zero-crossing period. They relate through the spectral shape.
Pierson-Moskowitz or JONSWAP — which spectrum?
Pierson-Moskowitz for fully developed open-ocean seas; JONSWAP (γ typically 3.3) for developing seas like the North Sea. The JONSWAP’s narrower band concentrates energy — harder on resonance avoidance.
How do waves set the compensator specification?
Hs through the vessel RAO sets the stroke; amplitude + period set the piston velocity; the natural period is tuned clear of Tp; damping balances resonance control against efficiency.
How much does compensation raise the operational Hs limit?
The page’s example: from 1.0 m uncompensated to 2.0–2.5 m with a well-designed passive unit — often the difference between a feasible operation and an impractical window. The economics are on weather windows.

Sizing a lift against this wave climate?

Wave climate sets the operational Hs limits. Send the lift location and we'll come back with the available weather windows.

Basis and assumptions

Where the figures on this page come from, and how far each one can be carried. Screening values are modelled estimates; they are not a substitute for a project-specific analysis on your own basis.

JONSWAP peak-enhancement factor γ = 1.0–7.0Published source / standard
The JONSWAP and Pierson–Moskowitz spectra, the γ range and its conventional mean of 3.3 are defined in DNV-RP-C205. γ = 1 reduces JONSWAP to the Pierson–Moskowitz form.
Spectrum curves on this pageIllustrative
The two spectra drawn here are generated for equal zeroth moment, so the shaded areas, and therefore the significant wave height, are genuinely equal between them. They illustrate spectral shape; they are not a hindcast of any particular location.
